AI Gateway Security: How We Keep LLM Gateway Secure

Two days ago, LiteLLM was compromised again: a poisoned release dumped every provider key its users had stored. In the same week we patched critical Next.js advisories, a Node.js security release and an account takeover in a popular auth library. AI is shrinking the time between a published bug and a working exploit.

So the question we hear most from security teams has changed. It used to be "are you SOC 2 compliant?" Now it is "You use AI to write code. How do you keep it secure?"

This post answers that with what actually ran in our repository: the routines, the review layers and the pull requests. LLM Gateway is open source, so every PR linked here is public.

What AI gateway security has to protect

An AI gateway sits between your application and every model provider you use. That makes AI gateway security a narrow but unforgiving problem. Our review brief, REVIEW.md, defines failure per area, and it reads like a threat model:

• Gateway: it leaks a provider key or another organization's data, misroutes or double-bills.
• API: it exposes data across organizations or skips a server-side permission check.
• Billing and webhooks: it breaks a webhook that Stripe or a provider retries.
• CI workflows: it runs fork code with a write token or lets a red check merge.
• Docs and marketing: it lies about current behaviour.

Everything below exists to catch one of those before it ships.

Routine 1: patch advisories in days, not quarters

Most breaches still start with a known bug in a dependency. Our dependency routine has three parts:

• Dependabot checks GitHub Actions daily, npm weekly across every workspace, and Docker monthly. All security updates land in one grouped PR instead of one per directory, and version updates wait out a five-day cooldown, so a freshly poisoned release has time to be caught before we adopt it.
• A scheduled security pass keeps one standing chore/security branch, recreates it from the latest main, and fixes every open critical and high advisory in the lockfile, with each advisory ID and the reason for each bump in the PR body.
• The runtime is pinned in one place. .tool-versions holds the Node.js version for CI, workflows, the devcontainer and the infrastructure Dockerfiles, so a runtime patch is a one-line change.

What that looked like this month:

Since August 1, we have merged 19 pull requests that patched dependency or runtime advisories.

Install scripts are a second front. pnpm only runs lifecycle scripts for an explicit allowlist in pnpm-workspace.yaml (esbuild, sharp and a handful of others), so a compromised transitive package cannot run code just by being installed.

Routine 2: a monthly AI security audit that needs evidence

AI produces security checklists quickly, and checklists are mostly noise. So our audit is built around evidence.

In October we added a security-audit agent skill to the repository. It merges OpenAI's security-best-practices (secure defaults per framework) with Cloudflare's security-audit (an evidence-first, six-phase audit workflow). Agents load it whenever they touch auth, sessions, API keys, billing, webhooks, user-supplied URLs or admin routes, and once a month it drives a full audit:

1. Reconnaissance maps the trust boundaries, seeded with the surfaces that matter here: auth, tenancy checks in every route, gateway keys, provider credentials, outbound URLs, Stripe webhooks, client IP trust, MCP and admin.
2. Hunting runs attack-class passes, including a dedicated one for prompt injection, tool calls and model output.
3. Validation turns each candidate into a record in findings.json, checked by a validator script. A best practice with no reachable boundary violation is not a finding.
4. Fix handles only confirmed findings: one finding per commit, the smallest change at the last trusted decision point, and a regression *.spec.ts next to the code.

Two rules keep this safe in a public repository. Findings and reports are never committed, because they describe unfixed vulnerabilities. And a fix PR names each finding by title and severity only, never a working exploit.

One finding fixed this month is #4494: a Vertex service-account JSON is user-supplied, and the server POSTed to whatever token_uri it contained. Fixed finding: SSRF via service-account token_uri, high. The token endpoint is now pinned to Google's, with a regression test that proves a foreign token_uri is ignored.

Routine 3: every pull request gets AI and human review

AI agents help write many of our pull requests, so review cannot be a rubber stamp. It works in layers:

• AI review on every PR. CodeRabbit loads REVIEW.md, so it hunts for the failures above rather than style. Findings must cite a file and line and are ranked Important, Nit or Pre-existing.
• Risk labels. The pr-risk workflow labels each PR risk: low, medium or high. Changes to migrations, the database schema, auth, payment and Stripe webhook routes, or CI workflows are always high risk, whatever their size, and request a maintainer review.
• Nothing is waved through. Every finding is fixed or resolved with a one-line reason, unresolved threads block the merge, and an approval covers one commit: a push after approval needs a fresh look.
• Fix it at the source. When a reviewer flags the same thing twice, the fix goes into an ESLint rule, a skill or REVIEW.md, not into the next PR description.
• Static analysis. GitHub code scanning runs alongside. It caught three polynomial ReDoS patterns (#3762) and a time-of-check race in our e2e workflow, where a commit pushed after a maintainer's /e2e comment could have run with provider secrets. That workflow now refuses any head pushed after the comment (#4318).

We also try things that do not work yet. This week we shipped a dedicated AI security review job and a hard merge gate, then pulled both the next day because they needed more work. They will come back in separate PRs. A security control that blocks good changes and lets reviewers tune it out is worse than none.

What the commits look like: closing SSRF one door at a time

Bring-your-own-key means tenants can point the gateway at their own provider endpoints. That is useful, and it is also the classic setup for server-side request forgery (SSRF). Here is one thread of work from the last three weeks:

• #4374 pins tenant DNS: sockets to tenant-controlled hosts resolve through a lookup that rejects private and reserved addresses at connect time, so the address used is the address checked.
• #4494 pins the GCP OAuth token endpoint.
• #4688 guards download URLs that providers return for videos and audio: HTTPS only, no internal hosts, redirects refused.
• #4719 rejects BYOK base URL overrides on the hosted service, and found a second door on the way: an Azure resource name was interpolated into a hostname without validation.
• #4723 moves the hostname check into one shared helper and validates the remaining endpoint options.
• #4725 refuses redirects on the GCP token exchange and stops copying upstream response bodies into errors and logs.
• #4775 routes video generation through the same guarded connection as every other endpoint.

None of these is dramatic on its own. That is the point: each review or audit pass finds the next door, and the fix generalises into a shared helper so the next endpoint gets it for free.

Keys and secrets fail closed

• LLM Gateway API keys are stored as HMAC fingerprints, never plaintext. The secret behind them is a keyring, so it can be rotated without breaking existing keys.
• Provider keys are encrypted at rest and must never reach logs or responses.
• No plaintext fallbacks. In August, #3821 removed every legacy plaintext path for API keys, provider keys and end-user sessions. A missing ciphertext now fails closed.
• You can rotate yours too. See API key rotation for zero-downtime rotation of your own keys.

Abuse is a security problem too

An AI gateway sells compute, so stolen cards and throwaway accounts are a constant. A few of the controls:

• Signups and email verifications are checked against AbuseIPDB. A flagged account is created as usual but cannot buy credits or run inference until a human approves it.
• Rate limits now key on the one client IP header our load balancer actually sets. Before #3749, the limiters read a header that never arrived, so every visitor shared one bucket.
• The docs Ask AI route validates requests before it counts them against the hourly model budget, so junk traffic cannot lock out real users (#4591).
• Support chat now requires a signed-in user with a verified email (#4755, #4767).

AI features get AI-specific controls

When a model can call tools, the tool call is the attack surface. When a user approves a connector tool, the API checks ownership and the saved proposal, then claims it before running anything, so a replayed or doubled approval cannot run a tool twice (#4598). Our content filter and guardrails run in the gateway, so the same policy applies to every provider behind it.

What you get as a customer

• SOC 2 Type II, audited over an observation period rather than on a single day.
• Audit events and log metadata in your SIEM through signed HTTPS data streams, on Enterprise.
• SSO and SCIM on Enterprise, so access follows your identity provider.
• Data retention you control, explained in LLM data retention.
• Private disclosure. Report vulnerabilities through a private GitHub security advisory, as described in our SECURITY.md.

Rules we hold AI-written code to

If you are working out how to secure your own codebase in the age of AI, these are the rules that made the difference for us:

1. Evidence is a file and a line. An AI finding without one is a guess.
2. One finding, one commit, one regression test.
3. Fix the class, not the instance. Move the check into a shared helper.
4. Humans own the high-risk paths. Auth, billing, migrations and CI always get a maintainer.
5. Never publish an exploit. Public PRs name the finding and its severity, nothing more.
6. Pull a control that does not work yet. Then bring it back properly.
